35:1 Metal Gearmotor 15.5Dx30L mm
This metal gearmotor is a compact (1.16" x 0.61" x 0.61") brushed DC motor with an enclosed 35:1 metal gearbox. These units have a 0.365"-long, 3 mm-diameter D-shaped output shaft.
Key specs at 6 V: 460 RPM and 60 mA free-run, 13 oz-in (1.0 kg-cm) and 0.8 A stall.
Alternatives available with variations in these parameter(s): gear ratio
|Description||Specs (8)||Pictures (2)||Resources (3)||FAQs (1)||On the blog (1)|
Discontinuation notice: This product is now only available by large-volume special order. Please contact us for more information. We recommend our micro metal gearmotors as alternatives; they have compatible output shafts, and versions are available with very similar performance characteristics to these discontinued gearmotors.
Dimensions of the 15.5D mm metal gearmotors. Units are mm over [inches].
This diagram is also available as a downloadable PDF (99k pdf).
This brushed DC gearmotor has a long (0.365" or 9.27 mm), 3 mm-diameter D-shaped metal output shaft that matches our assortment of Pololu wheels and the Solarbotics RW2 rubber wheel. Alternatively, our 3mm universal mounting hub can be used to mount custom wheels and mechanisms to the gearmotor’s output shaft, and you can use our 12mm hex wheel adapter to use this motor with many common hobby RC wheels.
The face plate has two mounting holes threaded for M2 screws, and you can use our custom-designed 15.5D mm metal gearmotor bracket (shown in the picture below) to mount the gearmotor to your project via these mounting holes and the screws that come with the bracket.
Pololu 15.5D mm metal gearmotor bracket with a 15.5D mm metal gearmotor.
These motors are intended for use at 6 V. In general, these kinds of motors can run at voltages above and below this nominal voltage, so they should comfortably operate in the 3 – 9 V range. Lower voltages might not be practical, and higher voltages could start negatively affecting the life of the motor.
Selecting the Right Gearmotor
We offer a wide selection of metal gearmotors that offer different combinations of speed and torque. Our metal gearmotor comparison table can help you find the motor that best meets your project’s requirements.
Some of the Pololu metal gearmotors.
