Power HD Standard Servo 3001HB

Pololu item #: 1058
Brand: Power HD
Status: Discontinued at Pololu
RoHS 3 compliant

This product has been discontinued.

Please consider the FEETECH FS5103B servo as an alternative. It has nearly identical dimensions and similar performance, and two servos should be generally interchangeable for most applications.

The 3001HB is a great, general-purpose, low-cost standard analog servo from Power HD. Two ball bearings help reduce friction and improve performance. This is one of our most popular standard-size servos. Servo horns and associated hardware are included.

Key specs at 6 V: 0.12 sec/60°, 61 oz-in (4.4 kg-cm), 43 g.

 Description Specs (9) Pictures (3) Resources (1) FAQs (2) On the blog (2)

Overview

The HD-3001HB is a great general-purpose, standard-size servo. Two ball bearings help reduce friction and improve performance. The lead is terminated with a standard “JR”-style connector, which is Futaba-compatible. You can find more information about this servo under the specifications tab and in its datasheet (379k pdf).

The picture below shows an example of the hardware that might be included with this servo (hardware might vary):

This servo is also compatible with our Mounting Bracket for Standard-Size Servos:

If you are looking for a similar servo that is capable of continuous rotation speed control as opposed to limited-range position control , consider the Power HD continuous rotation servo AR-3606HB, which has comparable size, weight, speed, and torque.

Note that, as with most hobby servos, stalling or back-driving this servo can damage it.

Comparison to the FEETECH FS5103B servo

The FEETECH FS5103B servo is a lower-cost alternative to the 3001HB with nearly identical dimensions and similar performance. The two servos should be generally interchangeable for most applications. The picture below shows both the FS5103B and the 3001HB side by side:
